IS 8783 (Part 4/Sec 3):1995
Winding Wires for Submersible Motors - Polyester and Polypropylene insulated wires
summary
Winding wires for submersible motors are specially insulated copper or aluminum conductors used in motor windings operating under water. Polyester and polypropylene insulation provides high dielectric strength, moisture resistance, thermal stability, and mechanical protection, ensuring reliable electrical performance in pumps used for agriculture, borewells, and industrial water systems.
Why BIS Certificate is Mandatory for Winding Wires for Submersible Motors - Polyester and Polypropylene insulated wires
BIS certification is mandatory to ensure electrical safety, insulation reliability, and long-term performance of winding wires used in submersible motors. These wires operate in high-moisture environments and electrical loads. BIS standards prevent insulation failure, short circuits, overheating, and motor damage, ensuring safety and regulatory compliance in India.
What is BIS Certified for Winding Wires for Submersible Motors - Polyester and Polypropylene insulated wires
The BIS certified specification defines requirements for conductor quality, insulation thickness, dielectric strength, resistance to moisture, thermal endurance, and mechanical properties. It also specifies performance tests such as breakdown voltage, insulation resistance, and heat shock testing to ensure winding wires are suitable for submerged motor applications.
Test required for Winding Wires for Submersible Motors - Polyester and Polypropylene insulated wires
| Title | Mandatory/Optional |
|---|---|
| Conductor Resistance | Required |
| High Voltage Test (Water Immersion Test) at room temperature | Required |
| Insulation Resistance (Volume Resistivity) at 27º C | Required |
| Overall Diameter | Required |
| Conductor Diameter | Required |
| Annealing Test | Required |
| Thickness of Insulation | Required |
| Insulation Resistance (Volume Resistivity at test temperature 85 º C) | Required |
| Heat Shock | Required |
| Shrinkage | Required |
| Hot Deformation | Required |
| Water absorption | Optional |
Benefits of BIS Certification for Winding Wires for Submersible Motors - Polyester and Polypropylene insulated wires
1. Enhanced Electrical Safety
BIS certification ensures proper insulation strength and dielectric performance, reducing risks of short circuits, leakage current, and electrical hazards in submerged motor systems.
2. Moisture and Heat Resistance Assurance
Certified wires are tested for resistance to water penetration and thermal stress, ensuring reliable operation under harsh underwater and high-temperature conditions.
3. Improved Motor Performance and Life
Standardized conductor quality and insulation thickness help prevent winding failures, improving motor efficiency and extending service life.
4. Legal Compliance and Market Approval
BIS certification is mandatory in India, allowing manufacturers and importers to supply winding wires legally without regulatory issues.
5. Increased Market Trust and Acceptance
BIS-marked products gain higher acceptance among pump manufacturers, contractors, and buyers, strengthening brand reputation and competitiveness.
